S175 Infant Swing Seat
This high-strength infant swing is constructed from bright, fade-resistant polyethylene and features a double-wall rotational molded design for added safety and durability. Engineered to support toddlers ages 2–3, it includes built-in ergonomic and structural enhancements that promote comfort and minimize forward tipping.
-
Seat Dimensions: 12" wide x 11" deep; 14" seat back height; 8" front depth
-
Leg Holes: 6.5" diameter
-
Crotch Band Width: 3"
-
Wall Thickness: 1.25"–1.5" spacing for added rigidity
-
Angle: Backrest tilted 7° off vertical for ergonomic balance
-
Drainage: Four 1" molded-in holes prevent water collection
-
Mounting: 4 integrated mounting points with counter-bored undersides for secure locknut encapsulation
-
Hanger: .375" stainless steel rod with welded shut, de-burred eyes and pivot joints
-
Tensile Strength: 5,000 lbs
-
Lifespan: 2 years in harsh environments; up to 5 years in optimal conditions
-
Chain Recommendation: 3' length for 8′ frame (adjust proportionately for higher frames)
Meets ASTM standards for commercial and residential use. Designed to provide safety, balance, and comfort for toddlers while resisting weather, wear, and vandalism.
